Frame
900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Fork
Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Wheel front
Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, 100x12 mm thru axle
Wheel rear
Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, Shimano 11/12 freehub, 142x12 mm thru axle
Skewer front
Bontrager Switch chamfered thru axle, removable lever
Skewer rear
Bontrager Switch chamfered thru axle, removable lever
*Tyre
Size: XS, S, M, ML, L, XL
Bontrager Aeolus RSL RD, Tubeless-Ready, cotton construction, aramid bead, 170 tpi, 700x28 mm
Size: XS, S, M, ML, L, XL
Pirelli P Zero Race, 120 tpi, tubeless-compatible, 700x28 mm
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
32 mm (as measured, see manual for details)
E-system
Battery
Charger
Charging cable included
Shifter
Shimano Dura-Ace R9270 Di2, 12 speed
Front derailleur
Shimano Dura-Ace R9250 Di2, braze-on, down swing
Rear derailleur
Shimano Dura-Ace R9250 Di2, 34T max cog
*Crank
Size: XS, S
Shimano Dura-Ace R9200, 52/36, 165 mm length
Size: M
Shimano Dura-Ace R9200, 52/36, 170 mm length
Size: ML, L
Shimano Dura-Ace R9200, 52/36, 172.5 mm length
Size: XL
Shimano Dura-Ace R9200, 52/36, 175 mm length
Bottom bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano Dura-Ace R9200, 11-30, 12-speed
Chain
Shimano Dura-Ace/XTR M9100, 12-speed
Max. chainring size
1x: 54T, 2x: 56/43
*Saddle
Size: XS, S
Aeolus RSL, carbon rails, 155 mm width
Size: M, ML, L, XL
Aeolus RSL, carbon rails, 145 mm width
*Seatpost
Size: XS, S, M
Madone aero carbon seat post, 0 mm offset, short length
Size: ML, L, XL
Madone aero carbon seat post, 0 mm offset, long length
*Handlebar/stem (integrated)
Size: XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 35 cm control width, 38 cm drop width, 80 mm stem length
Size: S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 90 mm stem length
Size: M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem length
Size: ML, L
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 100 mm stem length
Size: XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length
Rotor size
Max brake rotor sizes: 180 mm front, 160 mm rear
Weight
ML – 7.08 kg/15.61 lb (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
