Frame
Alpha Platinum Aluminium, internal storage, tapered head tube, internal guided routing, downtube guard, OCLV Next rocker link, Mino 4 link, ABP, Boost148, 120 mm travel
Fork
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel
Shock
X-Fusion Pro 2, 2-position damper, 185 mm x 50 mm
Max Compatible Fork Travel
140 mm
Hub Front
Bontrager alloy, 6-bolt, Boost110, 15 mm thru-axle
Hub Rear
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Skewer Rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
Tyre Size S
Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40"
Tyre Size M, ML, L, XL
Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
Frame: 29x2.50", Fork: See manufacturer
Shifter
Shimano Deore M6100, 12-speed
Rear Derailleur
Shimano Deore M6100, long cage
Crank
Shimano MT512, 30T ring, 55 mm chain line, 170 mm length
Bottom Bracket
Shimano BB-MT501 BSA
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Max. Chainring Size
1x: 34T, min 30T
Saddle
Bontrager Verse P3, steel rails
Seatpost Size S
TranzX JD-YSI22, 100 mm travel, internal routing, 34.9 mm, 346 mm length
Seatpost Size M, ML, L, XL
TranzX JD-YSI22, 170 mm travel, internal routing, 34.9 mm, 497 mm length
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Brake
Shimano MT200 hydraulic disc
Rotor Size
Max brake rotor sizes – Frame: 200 mm, min 180 mm, Fork: see fork manufacturer
Bag
Bontrager BITS Internal Frame Storage Bag
Weight
M - 15.90 kg / 35.06 lbs
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
