Frame
Alpha Platinum Aluminium, internal storage, tapered head tube, internal guided routing, downtube guard, OCLV Next rocker link, Mino 4 link, ABP, Boost148, 120 mm travel
Fork
Fox Rhythm 34, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 130 mm travel
Shock
Fox Performance Float DPS, 3-position damper, 185 mm x 50 mm
Max Compatible Fork Travel
140 mm
Wheel Front (Size: S)
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5"
Wheel Front (Size: M, ML, L, XL)
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
Wheel Rear
Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 54, 6-bolt, Boost148, 12 mm thru axle
Skewer Rear
Bontrager Switch thru-axle, removable lever
Tyre (Size: S)
Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40"
Tyre (Size: M, ML, L, XL)
Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
Frame: 29x2.50", Fork: See manufacturer
Shifter
Shimano XT M8100, 12-speed
Rear Derailleur
Shimano XT M8100, long cage
Crank
Shimano Deore M6120, 30T ring, 55 mm chainline, 170 mm length
Bottom Bracket
Shimano BB-MT501 BSA
Cassette
Shimano SLX M7100, 10-51T, 12-speed
Chain
Shimano SLX M7100, 12-speed
Max. Chainring Size
1x: 34T, min 30T
Saddle
Bontrager Verse P3, chromoly rails
Seatpost (Size: S)
Bontrager Line Dropper, 100 mm travel, MaxFlow, internal routing, 34.9 mm, 310 mm length
Seatpost (Size: M, ML, L, XL)
Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
Handlebar
Bontrager Line, alloy, 35 mm, 27.5 mm rise, 780 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Elite, 35 mm, 0-degree, 45 mm length
Brake
Shimano 4-piston hydraulic disc, M6100 lever, M6120 calliper
Brake Rotor
Shimano RT66, 6-bolt, 180 mm
Rotor Size
Max brake rotor sizes – Frame: 200 mm, min 180 mm, Fork: see fork manufacturer
Bag
Bontrager BITS Internal Frame Storage Bag
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
